New BS Education Plus Band Saw Range

price £POA+VAT

A special series of band saw, designed and engineered to give technicians and students maximum security combined with the traditional solidity and quality of an ACM band saw.

Like all ACM Machines our Education Plus Band Saws are manufactured in Italy

Our New Education Plus Range use the same construction as our normal BS Education Range but include addition features:

  • LED: Indicator of Machine Status: shows when blade is running
  • PERIMETER SPACE: with Micro Switches Increases Student Safety
  • WORK LIGHT: Lighting of Cutting Area
  • Available as 440 - 540 and 640 - in 240 or 415 Volt models

Education Plus Band Saw Range comes with as standard:

  • Led Indicator
  • Perimeter Spacers with Safety Microswitches
  • Light In Cutting Area
  • Solid Band Wheels, Rubbered Covered
  • Cleaning Brush on Lower Wheel
  • Tilting Table 0-20 Degrees
  • Upper and Lower Roller Blade Guides
  • Self Releasing Kick Stop
  • Blade Tension Indicator
  • Key Locked Security System on Doors and Isolator
  • Manufactured in Italy for Consistency and Quality
  • Electro-Mechanical Motor Brake

View our video of our BS Education Plus Bandsaw

Click Image to Enlarge

Specification

  BS440 PLUS" BS540 PLUS" BS640 PLUS
Solid Band Wheels Diameter 440mm* 540mm* 640mm*
Blade Speeds 1600m/min 1600m/min 1600m/min
Motor power hp 2hp 3hp 3hp
Cutting Height Max. 320mm 350mm 400mm
Cutting Width Max. 410mm 520mm 620mm
Blade Length Min:3650mm - Max:3700mm Min:4200mm - Max:4260mm Min:4770mm - Max:4810mm
Dust Suction Outlet 2xØ120 2xØ120 2xØ120
Table Size 420 x 580mm 520 x 720mm 600 x 885mm
Overall Dimensions (W x D x H) 830 x 560 x 1860mm 1540 x 1170 x 2310mm 1700 x 1250 x 2500mm
Overall Packing Dimensions 900 x 700 x 2200mm 1200 x 800 x 2170mm 1200 x 800 x 2360mm
Net Weight 200kg 260kg 380kg

Optional Accessories

Protractor Square Mod2 Goniometric Square Mod1 Lower blade guide with bronze and ceramic elements Upper blade guide with bronze and ceramic elements Wheels for moving - Mobility kit
